Ultra High Frequency Specifications and Properties
| Category | Series | Equipment Model No. |
Max Input Power | Max Input Current | Output Oscillation Frequency | Input Voltage(V) | Duty Cycle |
|---|---|---|---|---|---|---|---|
| Ultra High Frequency Series | MAG-04C Series |
MAG -04C Normal Type MAG -04AC Auto-Control Type |
4KW | 15A | 100-250KHZ | Single-phase 220V | 80% |
| MAG-03 Series |
MAG -03 Normal Type MAG -03A Auto-Control Type |
3KW | 15A | 200-700KHZ | 100% | ||
| MAG-06 Series |
MAG -06-I Normal Type MAG -06A-I Auto-Control Type |
6KW | 30A | 150-500KHZ | 100% | ||
|
MAG -06-II Normal Type MAG -06A-II Auto-Control Type |
6KW | 30A | 200-700KHZ | 100% | |||
|
MAG -06-III Normal Type MAG -06A-III Auto-Control Type |
6KW | 30A | 0.4-1.1MHZ | 100% | |||
| MAG-10 Series |
MAG -10-I Normal Type MAG -10A-I Auto-Control Type |
10KW | 15A | 100-350 KHZ | Three Phase 380V-415V | 100% | |
|
MAG -10-II Normal Type MAG -10A-II Auto-Control Type |
10KW | 15A | 150-500 KHZ | Single Phase 380V-415V | 100% | ||
| MAG-20 Series |
MAG -20B Split Type MAG -20AB Auto-Split Type |
20KW | 30A | 50-250 KHZ | Three Phase 380V-415V | 100% | |
| MAG-30 Series |
MAG -30B Split Type MAG -30AB Auto-Split Type |
30KW | 45A | 50-200 KHZ | Three Phase 380V-415V | 100% | |
| MAG-40 Series |
MAG -40B Split Type MAG -40AB Auto-Split Type |
40KW | 60A | 50-200 KHZ | Three Phase 380V-415V | 100% | |
| MAG-60 Series |
MAG -60B Split Type MAG -60AB Auto-Split Type |
60KW | 90A | 50-150 KHZ | Three Phase 380V-415V | 100% | |
| MAG-100 Series |
MAG -100B Split Type MAG -100AB Auto-Split Type |
100KW | 150A | 30-100 KHZ | Three Phase 380V-415V | 100% |
